Product Summary
The ATTL7581BAE-DT offers break-before-make or make-beforebreak switching. It is with simple logic level input control. Because of the solid-state construction, the voltage transients generated when switching into an inductive ringing load during ring cadence or ring trip are minimized.
Parametrics
Absolute maximum ratings: (1)Operating Temperature Range: –40 to 110 ℃; (2)Storage Temperature Range: –40 to 150 ℃; (3)Relative Humidity Range: 5 to 95 %; (4)Pin Soldering Temperature: 10 ℃; (5)5 V Power Supply: 7 V; (6)Battery Supply: –85 V; (7)Logic Input Voltage: 7 V; (8)Input-to-output Isolation: 330 V; (9)Pole-to-pole Isolation: 330 V.
Features
Features: (1)Small size/surface-mount packaging; (2)Monolithic IC reliability; (3)Low impulse noise; (4)Make-before-break, break-before-make operation; (5)Clean, bounce-free switching; (6)Low, matched ON-resistance Built-in current limiting, thermal shutdown, and SLIC protection; (7)5 V only operation, very low power consumption; (8)Battery monitor, all OFF state upon loss of battery; (9)No EMI; (10)Latched logic level inputs, no drive circuitry; (11)Only one external protector required.
